Kuka Robot Data Cable

The Kuka Robot Data Cable, also known as the KUKA Encoder Cable (Model No. 00-174-775), is an essential communication component for KUKA C4 robot controllers, specifically connecting to X21/X31 interface ports. This cable ensures precise data transmission between the encoder and controller, supporting high-performance robot motion and stability in automated applications.

Product Specification

Design Considerations

The KUKA Robot Encoder Cable is engineered to meet demanding industrial requirements, with key design focuses on:

• Stability – Delivers stable power and signal transmission for uninterrupted robotic operation.

• Reliability – Resistant to mechanical wear and electrical interference, ensuring long-term performance.

• Safety – Meets fire and electrical safety standards to prevent hazards such as electric shock or short circuits.

Durability & Protection

• Flame-retardant sheath: Rated VW-1 for superior fire resistance in harsh factory environments.

• Industrial-grade insulation: Reduces the risk of signal loss and external electromagnetic interference.

• Robust mechanical build: Designed to resist bending, abrasion, and cable fatigue over extended use cycles.

Maintenance Guidelines

To ensure the long-term stability and safety of your KUKA robot system, regular encoder cable maintenance is essential:

1. Routine Inspection – Periodically check connections, insulation integrity, and signal stability.

2. Prompt Replacement – Replace the cable immediately if wear, damage, or failure is detected.

3. Protective Routing – Use appropriate cable trays or protection sleeves to avoid external damage.

Application Scope

This cable is widely used in:

• Industrial automation lines

• KUKA robotic welding and assembly stations

• Warehouse and logistics robots

• Medical automation equipment

FAQ – KUKA 00-174-775 Robot Data Cable

What is the KUKA 00-174-775 Data Cable used for?
This cable is designed to connect KUKA robots (typically with C4 controllers) to encoder ports such as X21/X31. It transmits encoder signals to ensure accurate robot movement and position feedback.

Which robot models are compatible with this encoder cable?
The cable is compatible with KUKA robots using C4 controllers, especially models that use the X21 or X31 interface ports. Always verify your robot’s documentation or consult us before purchasing.

What are the available lengths of the cable?
Standard cable lengths include 7m, 15m, 25m, 35m, and 50m. Custom lengths can be produced upon request.

Is the cable resistant to fire or harsh environments?
Yes. The cable meets VW-1 flame retardant standards and is built with high-strength, insulated materials suitable for industrial environments.

Can I use this cable as a replacement for a damaged original?
Yes. The 00-174-775 cable can be used as a direct replacement for original KUKA encoder/data cables, provided the connector type and interface match.

Does this cable support shielding from electromagnetic interference (EMI)?
Yes. The cable features industrial-grade shielding to protect encoder signal integrity and prevent electromagnetic interference.
