KUKA X19 X19.1 Teach Pendant Extension Cable

KUKA X19 X19.1 Teach Pendant Extension Cable

KUKA Robot Teach Pendant Cable  is a cable that connects the teach pendant to the industrial robot. (00-174-900  00-174-901  00-174-902    00-323-688). KUKA Robot Teach Pendant Cable  is a cable that connects the teach pendant to the industrial robot. (00-174-900  00-174-901  00-174-902    00-323-688). Teach Pendant Extension Cable allows you to extend the reach of the teach pendant, providing more freedom of movement and enabling operators to work comfortably at a distance from the robot controller.These extension cables are designed and manufactured by KUKA to ensure reliable and secure communication between the teach pendant and the robot controller, maintaining the same level of performance as the original cable.

PRODUCT SPECIFICATION:

How KUKA X19 X19.1 Teach Pendant Extension Cable works

• Signal transmission: The extension cable contains lines for transmitting various signals, including control instructions, feedback signals, etc. These signals are key for communication between the operator panel and the controller. Through these signals, the operator can convey instructions to the robot and obtain feedback on the robot's operating status.

• Power Transmission: Extension cables also include lines used to transmit power. These lines transmit power from the controller to the operator panel to ensure proper operation of the operator panel. In addition, extension cables may also include lines for carrying other power signals, such as power for backlights or other add-on devices.

Precautions:

• Installation location: Make sure the extension cable is properly connected between the robot operating panel and controller, and install it in a location where it is not susceptible to damage or interference. Avoid placing cables in areas where they may be impacted by robot movement or other objects.

• Power supply matching: When using extension cables, ensure that the power supply used matches the requirements of the robot operation panel. Avoid using a power supply that is too large or too small to avoid affecting the normal operation of the cable and the stability of the robot operation panel.

• Waterproof and dustproof: If the operating environment is humid or dusty, you should choose a waterproof and dustproof extension cable to ensure its reliability and durability in harsh environments.

• Avoid bending and stretching: During installation and use, avoid excessive bending or stretching of the extension cable to avoid damaging the wiring or connectors inside the cable and affecting its normal operation.

• Periodic Inspections: Regularly inspect the appearance of the extension cable to make sure there is no obvious damage or wear. If any damage or abnormality is found, stop using it immediately and have it repaired or replaced.

• Avoid interference: Try to avoid placing extension cables in areas that may be subject to electromagnetic interference to ensure the stability and reliability of signal transmission.

• Professional Installation: If you are unfamiliar with installing or connecting extension cables, seek professional help or guidance to ensure installation is done correctly and complies with relevant safety standards and regulations.

About Us

Super Dragon Electric Technology(DongGuan) Co.,LTD is a manufacturing enterprise dedicated to the production and sales of robot wire harness products. If you are interested in our Robot Cables, feel free to enquiry at any time.

FAQ：

What is KUKA X19 X19.1 Teach Pendant Extension Cable?

KUKA X19 X19.1 Teach Pendant Extension Cable is an extension cable used to connect the KUKA robot operation panel (Teach Pendant) and the controller.

What is the purpose of this extension cable?

Its function is to realize the connection between the robot operation panel and the controller, and to transmit control instructions, feedback signals and power supply, thereby realizing the control and monitoring of the robot.

How should the installation location of the extension cable be selected?

You should choose a location that is not susceptible to damage or interference, and avoid placing it in an area where it may be hit by robot movement or other objects.

What power issues should I pay attention to when using extension cables?

Make sure that the power supply used meets the requirements of the robot operation panel and avoid using a power supply that is too large or too small to ensure the normal operation and stability of the cable.

How to protect extension cables from water and dust?

Water and dustproof extension cables are available to ensure reliability and durability in wet or dusty environments.

What should you avoid when installing and using extension cables?

You need to avoid bending or stretching the cable excessively to avoid damaging the internal wiring or connectors.

How to check extension cables regularly?

The appearance of the cable can be checked regularly to ensure that there is no obvious damage or wear. If any abnormality is found, it should be stopped immediately and repaired or replaced.

Why do you need to avoid placing extension cables in areas where they may be subject to electromagnetic interference?

This is to ensure the stability and reliability of signal transmission and avoid the impact of electromagnetic interference on the extension cable.

What should I do if I'm not familiar with installing extension cables?

You can seek professional help or guidance to ensure that the installation is correct and complies with relevant safety standards and regulations.

What are the benefits of using KUKA X19 X19.1 Teach Pendant Extension Cable?

It can expand the scope of use of the robot operation panel, increase operational flexibility and convenience, and improve robot operation efficiency and work results.
